ADDITIONAL INFORMATION:
Alemite reels are the standard for quality and durability in the lubrication industry. High attention to detail in material selection, construction and testing ensure that Alemite reels perform well – every time – providing a key component in a safe and efficient operation.
DEF (DIESEL EXHAUST FLUID) HOSE REELS
Alemite’s heavy duty hose reels deliver Diesel Exhaust Fluid (AUS32, Aqueous Urea Solution) in two reel capacities– 30 - 50 ft (9.1 - 15.2 m). Specifically designed for DEF systems, the reels are engineered to perform better, last longer and are safer to maintain and operate. Reels can be mounted overhead, on a wall, floor or tank.
FEATURES:
• Easily adjustable guide arm
• Spring powered and self-retracting
• Ratchet type latch
• Gasket-sealed spring case
• Durable powder coat finish
• Balanced-pressure swivel
• Stainless steel shaft and swivel sealed with FKM o-rings
• Heavy-gauge steel construction
• Adjustable hose stop
COMPATIBILITY
• Diesel Exhaust Fluids (DEF)
RELATED PRODUCTS
• 2 ft. (0.6 m) connecting DEF Hose (343143-2)
• Stainless Steel 1/2" (13 mm) BSPP female x 3/4" (19.1 mm) BSPP male adapter (343196)
• 30 ft. (9 m) DEF Hose Assembly (393539-157)
• 50 ft. (15 m) DEF Hose Assembly (393539-158)
|
Product # |
Color |
Max Pressure |
Delivery Hose |
Reel Inlet |
Weight |
||
|
Specification |
Part # |
Outlet |
|||||
|
8072-A |
Maroon |
300 psi (20 bar) |
1/2" ID x 30 ft |
393539-159 |
1/2" BSPP |
1/2" BSPP |
47 lb (21 kg) |
