| Capacity (tons) |
25 |
. |
| Stroke (in.) |
6.26 |
. |
| Model # |
SD256 5 |
. |
| Cylinder Effective Area (in.2) |
5.14 |
. |
| Oil Capacity (in.3) |
32.2 |
. |
| Collapsed Height (in.) |
12.42 |
(A) |
| Extended Height (in.) |
18.68 |
(B) |
| Outside Diameter (in.) |
4 |
(C) |
| Cylinder Bore Dia. (in.) |
2.56 |
(D) |
| Plunger Diameter (in.) |
2.17 |
(E) |
| Base to Coupler Port (in.) |
1 |
(F) |
| Saddle Distance above Cyl. (in.) |
0.39 |
(G) |
| Piston Internal Thread (in.) |
1 1/2-16UNC |
(H) |
| Piston Thread Length (in.) |
1 |
(I) |
| . |
. |
. |
| Base Mounting Holes |
– |
. |
| Bolt Circle (in.) |
– |
(J) |
| – |
– |
(K) |
| Thread Depth (in.) |
– |
(L) |
| . |
. |
. |
| Collar Thread (in.) |
4″-12UNC |
(M) |
| Collar Thread Length (in.) |
1.61 |
(N) |
| Saddle Diameter (in.) |
2 |
(O) |
| Weight (lbs.) |
41.45 |
