| Capacity (tons) |
30 |
. |
| Stroke (in.) |
6.01 |
. |
| Model # |
SA306 |
. |
| Cylinder Effective Area (in.2) |
6.85 |
. |
| Oil Capacity (in.3) |
41.2 |
. |
| Collapsed Height (in.) |
11.09 |
(A) |
| Extended Height (in.) |
17.1 |
(B) |
| Outside Diameter (in.) |
3.94 |
(C) |
| Cylinder Bore Dia. (in.) |
2.95 |
(D) |
| Plunger Diameter (in.) |
2.56 |
(E) |
| Base to Coupler Port (in.) |
1.07 |
(F) |
| Saddle Distance above Cyl. (in.) |
0.12 |
(G) |
| Piston Thread Length (in.) |
0.47 |
(I) |
| Base Mounting Holes |
|
. |
| Bolt Bolt Circle (in.) |
3.15 |
(J) |
| Thread |
M6 x P1.0 |
(K) |
| Thread Depth (in.) |
0.47 |
(L) |
| Saddle Diameter (in.) |
2.22 |
(O) |
| Weight (lbs.) |
16.72 |
