ADDITIONAL INFORMATION:
FEATURES
- Cooler line and dipstick exchange modes
- Select any quantity from 1-20 quarts
- Power interruption memory
- Drains vehicle’s transmission for filter change
- 24-quart new and waste fluid tanks
- Easy to use
- Pause button
- Fully automatic operation
- Large 2.5 gallon-per-minute pump performs faster exchanges
- 12 volt powered
- Proven, accurate fluid measurement (+/-3%)
- Individual add and remove fluid buttons
- Voltmeter
- Quart counter
BENEFITS
- Large backlit LCD screen provides valuable information and walks the technician through the service making for a faster and easier exchange
- Roto-cast polyethylene body won’t scratch vehicle
- Adapter rack drains into the waste tank keeping the adapters neat & organized
- 5-inch locking caster wheels
- Small platform does not take up a lot of room
- Clear service hoses provide visual confirmation of fluid exchange
- Perform more services and generate more revenue than with traditional ATF exchange equipment
SPECIFICATIONS
Dimensions: 39”H x 24 3/4”W x 25”D
Fluid Tanks: 24 qt. new & waste
Power: 12V DC from vehicle’s battery
Weight: 95 lbs.
CHAPTERS:
Priming the Machine - 0:49
Dipstick Exchange (with Cleaning) - 1:58
Dipstick Exchange (with Filter Change) - 6:38
Inline Exchange (with Cleaning) - 10:35
Draining the New Fluid Tank - 16:08
Draining the Waste Fluid Tank - 17:10
Voltage Monitor - 18:09
Cycle Valves - 18:30
Filter Replacement - 19:01
